| 筛宽 (cm) |
产量(小麦) (t/h) |
风压 (pa) |
吸风量 (m3/h) |
振幅 (mm) |
筛面倾角 (°) |
动力(kW) | 振频 (次／min) |
重量 (kg) |
外形尺寸 长×宽×高 (mm) |
|
| TQSF43 | 43 | 1-1.5 | ＜980 | 3000 | 4-5 | 5-9 | 2×0.25 | 960 | 215 | 1270×700×1600 |
| TQSF50 | 50 | 2-4 | ＜980 | 4000 | 4-5 | 5-9 | 2×0.25 | 960 | 230 | 1420×780×1800 |
| TQSF60 | 60 | 3-5 | ＜980 | 4500 | 4-5 | 5-9 | 2×0.25 | 960 | 280 | 1450×876×1800 |
| TQSF80 | 80 | 5-7 | ＜980 | 6000 | 4-5 | 5-9 | 2×0.25 | 960 | 340 | 1450×1046×1800 |
| TQSF100 | 100 | 7-9 | ＜980 | 8000 | 4-5 | 5-9 | 2×0.25 | 960 | 400 | 1500×1246×1900 |
| TQSF125 | 125 | 9-11 | ＜980 | 10200 | 4-5 | 5-9 | 2×0.25 | 960 | 500 | 1470×1496×1920 |
| TQSF150 | 150 | 11-14 | ＜980 | 12000 | 4-5 | 5-9 | 2×0.25 | 960 | 600 | 1580×1746×1920 |
| TQSF175 | 175 | 14-18 | ＜980 | 15000 | 4-5 | 5-9 | 2×0.25 | 960 | 750 | 1470×1990×1920 |
| TQSF200 | 200 | 16-20 | ＜980 | 17000 | 4-5 | 5-9 | 2×0.25 | 960 | 1000 | 1470×2292×1920 |
| TQSF250 | 250 | 20-22 | ＜980 | 20400 | 4-5 | 5-9 | 2×0.25 | 960 | 1050 | 1470×2835×1920 |
